HHXg5 RIDe-ON TROWeL • paRTs maNuaL — Rev. #6 (03/27/14) — page 5

SuGGEStED SpaRE paRtS

HHXg5 RIDe-ON TROWeL WITH B & s vaNguaRD Dm950 g eNgINe

1 to 3 units

Qty.

p/N

Description

3............23284-100 ............FuSE, 10 AMP ATC/ATO

3............23284-300 ............FuSE, 30 AMP ATC/ATO

1............12017 ....................RELAY,KILL # HELLA # 87411B

1............406000 ..................ROCKER, LIGHT SWITCH, ON-OFF

1............20165 ....................PALM HANDLE KIT, L/R HANDLES W/O BOOT

2............12548 ....................PuMP, SPRAY, SHuRFLO 100-000-21

3............22347 ....................LIGHT, HELLA 50W BOTTOM MOuNT #996361617

1............23152 ....................CABLE, THROTTLE

2............2829 ......................ARM, TROWEL HD EXTENDED

6............11039 ....................BuSHING, TROWEL LARGE ARM

3............9111 ......................SPRING, LS H ARM RETuRN STD BOSS

3............2143 ......................SPRING, RS H ARM RETuRN STD BOSS

1............21208 ....................SPIDER KIT, 5BLD HHN SERVICE KIT

2............20938 ....................THRuST ASM, SERVICE HTH, HHN, HTO TROWELS

1............23262 ....................CYLINDER, HYDRAuLIC STEERING ASSY

1............23275-02 ..............ELEMENT, 10 MICRON FILTER

2............820314 ..................OIL FILTER

2............820311 ..................FuEL FILTER

2............M113621 ...............AIR CLEANER ELEMENT

1............22408 ....................GAuGE, MuLTI

2............821075 ..................V-BELT, ENGINE

2............20138 ....................BELT, CVT CLuTCH COMET #302609 DF

2............

23365 .....................BELT, CVT MuLTI-CLuTCH

1............10958 ....................SWITCH, IGNITION, HONDA/VANGuARD TWINS, W/KEYS

1............821135 ..................SWITCH, OIL PRESSuRE

1............820208 ..................SWITCH, WATER TEMPERATuRE

1............825064 ..................THERMOSTAT

NOTICE

Part numbers on this Suggested Spare Parts list may

supersede/replace the part numbers shown in the

following parts lists.
