HHXg5 RIDe-ON TROWeL • paRTs maNuaL — Rev. #6 (03/27/14) — page 43
EnGInE CLutCh aSSY. (OLD StYLE)
NO. paRT NO. paRT Name QTY. RemaRKs
1 23044 STuB SHAFT, CVT CLuTCH 33MM 31/34V 1
2 22021 SCREW, HHFS M8-1.25X20MM TENSILOK PATCH 5
3 CLuTCH, DRIVE CVT ........................................................1 ...........NO LONGER AVAILABLE
.......................................................................................................... uSE KIT P/N 23447 TO uPGRADE
...............................................................................................................TO MuLTI-CLuTCH SYSTEM
4 2955 WASHER, LOCK 7/16 ZINC 1
5 9164 SCREW, HHC 7/16-20X6.00 GR8 PATCH 1
6 20138 BELT, CVT CLuTCH COMET #302609 DF 2
7 2429 BELT HOLDER, CVT SPARE BELT 1
8 15226 SCREW, HHF M8-1.25 X 25MM 1
9 23447 KIT, MuLTCLuTCH uPGRADE 1
10 23291 TOOL, CLuTCH REMOVAL 1
NOTICE
Multi-Clutch components are not interchangeable with the prior Hoffco
Comet drive system. The Hoffco Comet CVT system must be replaced
with Multi-Clutch components in the event of a Hoffco Comet clutch failure.
