WRS5200 RIDe-ON ROLLeR SCReeD • paRTS maNuaL — Rev. #1 (11/12/10) — page 45
NO. paRT NO. paRT Name QTY. RemaRKS
1 16409 MOTOR, PARkER 110A-106-A-O ..........................1 ...............INCLUDES ITEMS W/@
2@ 16629 NUT, NyLOC 1/2-13 GD 8 2
3@ 16630 WASHER, FLAT SAE 1/2 HI STREN 2
4@ 10024 NUT, NyLOC 1/4-20 1
5@ 4538 SCREW, HHC 1/4-20 X 2-1/2 GR 5 1
6@ 0457 SCREW, SHS 3/8-24 X 1/2 CUP POINT, ZINC 2
7@ 16298 COUPLING, STRIkER TUBE 2
8@ 36297 NUT, JAM 5/8-18 X .300 2
9@ 26293 PIN, FRONT MOTOR 2
10@ 16526 SCREW, HHC 1/2-13 X 1-3/4 GRD 8 2
11@ 7170 PIN, HITCH CLIP, 5/32 X 3-5/16 1
12 26896 FITTING, NUT 12 BLkHD JAM 1
13 16575 HOSE, 75" OAL 5/8HOSE-10FJX12FJ 1
14 16333 FITTING, STR 6MJ-6MJ BLkHD UNION
15 16576 HOSE, 3/8X78" - 3/8FJ X 45°3/8FJ 1
16 16581 FITTING, 90 6MJ-4MO 1
17 16336 FITTING, 45 10MJ-10MO 2
strikE tubE MOtOr assy.
