WRS5200 RIDe-ON ROLLeR SCReeD • paRTS maNuaL — Rev. #1 (11/12/10) — page 37
HyDraulic tank / cOOlEr assy.
NO. paRT NO. paRT Name QTY. RemaRKS
1 16317 TANk, HyDRAULIC 1
2 16405 CAP, HyDRAULIC 1
3 3336 GAUGE, SIGHT 1
4 9154 SCREW, HHC 3/8-16 X 1-3/4 4
5 10136 WASHER, FLAT 3/8 SAE 4
6 10133 NUT, NyLOC 3/8-16 4
7 16218 FILTER, HEAD ZINGA ZAF-10-25-0 2
8 11402 ELEMENT, FILTER 3" 10 MICRON AE-10 2
9 16346 FITTING, BUSH 3/4FP - 1MP 3
10 13220 FITTING, STR 12BARB-3/4MP 3
11 3333 CLAMP, HOSE WORM #12 11/16 TO 1-1/4 4
12 3462 HOSE, .75 ID 100R4 16.5 LONG 2
14 16572 FITTING, STR 8M0-3/4FP SWIV 1
15 3461 FITTING, 90 12BARB-12MO 1
16 16331 FITTING, STR 10MJ-3/4MP 1
17 26992 HOSE ASM, 1/2ID X 46, 10FJ X 45DEG 10FJ 1
18 3368 FITTING, 90 10MJ-3/4MP 1
19 26993 HOSE ASM, 1/2 ID X 48, 10FJ X 10FJ 1
20 16570 COVER, FEMALE 3/4 H6-65M 1
21 16566 FITTING, QD PARkER H6-62 FEM 3/4FP 1
22 16571 COVER, MALE 3/4 H6-66M 1
23 16567 FITTING, QD PARkER H6-63 MALE 3/4FP 1
24 16585 FITTING, BUSH 1/2FP-3/4MP 2
25 16597 FITTING, STR 10MJ-1/2MP BLkHD 3
26 16598 FITTING, NUT 10 BLkHD JAM 2
27 36710 HOSE ASSy, 5/8"ID X 27.25" 1
28 3365 FITTING, STR 10MJ-10MO 1
29 11721 FITTING, STR 6MJ-6MO 3
30 16611 HOSE ASM, 6FJSWX-6FJSW45° 2
32 36567 HOSE ASM, .38"ID X 14.5" - 6FJ SWIVEL STR 1
33 21093 FITTING, TEE 10MJ-10MJ-10MO RUN 1
34 16698 FITTING, 45 10MJ-10FJ 1
35 16846 FITTING, 90 10MJ-10FJ 1
36 36713 HOSE ASM, 1/2"ID X 14.50" 1
37 36712 HOSE ASM, 1/2"ID X 17.25" 1
38 16565 FITTING, QD PARkER H4-63 MALE 1/2FP 1
39 16569 CAP, DUST PARkER H4-66M 1
40 16213 COOLER, THER TRANS 1
41 16336 FITTING, 45 10MJ-10MO 2
42 36674 FITTING, STR 16MO X 10FO 2
