EM120P/S HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #5 (09/15/11) — PAGE 61
5 LUG HUB AND WHEEL (1-1/16 AXLE SPINDLE)
S/N GE21000 AND ABOVE
MAY 2000 AND ABOVE
NO PART NO PART NAME QTY. REMARK
1 13212 GROMMET .............................................. 1 ............. WITH DUMP (HYDRAULIC DUMP CYL.)
2 EM941280 LUG NUT 8
3 13120 MAIN FRAME .......................................... 1 ............. S/N KA26943 TO II27769
................................................................................ NO LONGER AVAILABLE. USE 13365.
3 13365 MAIN FRAME .......................................... 1 ............. S/N II27770
4 10133 LOCK NUT 3/8-16 1
5 0447 FLAT WASHER 1/2" 1
6 10176 LOCK NUT 1/2-13 12
7 511493 GRATE LATCH 1
8 1023 HHCS 3/8-16 X 1.1/4" 1
9 13280 DRUM LOCK LEVER ............................... 1 ............. W/O DUMP (MANUAL ONLY)
10 3102 HANDLE GRIP ........................................ 1 ............. W/O DUMP (MANUAL ONLY)
11 EM941278 DUST CAP .............................................. 2 ............. REPLACEMENT ONLY
12 13363KIT SAFETY CHAIN ASM ............................. 1 ............. REPLACES 3148
13 3028 U-BOLT 2
14 3215 HHCS 1/2-13 X 3-1/2" 1
15 HLC-1 TOW BAR (LOOP) ................................... 1 ............. CONTACT UNIT SALES
15 HPC-1 TOW BAR (1 " PIN) ................................. 1 ............. CONTACT UNIT SALES
15 HBC-1 TWO BAR (BALL HITCH 2 -INCH) .......... 1 ............. CONTACT UNIT SALES
16 511699 AXLE, NEW STYLE 1
17 5218 HHCS 1/2-13 X 1-1/2" 4
18 3043 HHCS 1/2-13 X 6" 2
19 3076 AXLE SPRING 2
20 3018 LEAF SPRING 2
21 19045 WHEEL & TIRE 2
22% EM968302 CASTLE NUT, 3/4-16 2
23 0183 COTTER PIN, 1/8X1-1/4 2
24% EM923161 FLAT WASHER 3/4" 2
25% EM903168 BEARING CONE INNER 4
26% EM903169 BEARING CUP INNER 4
27% EM914324 SEAL 2
28 EM941277 HUB W/BEARING CUPS (5-LUG) ............ 2 ............. INCLUDES ITEMS W/%
30% EM903113 BEARING CONE OUTER 2
31% EM903012 BEARING CUPS OUTER 2
32 516180 SAFETY HOOK 1
FRAME 3 ASSY.
