QP2TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #2(08/14/14) — PAGE 31
PUMP ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
38 0151191257 STUD BOLT (DRAIN COVER HANDLE) 4
M12 X 57 X15 X 22
39# 0520030310 KEY, 4.7 X 21 1
40 43592012400011 IMPELLER WASHER, 35 X 9 T4.5 1
41 0204490060 U-NUT (WEAR PLATE), M6 3
42 0205490080 NUT, ENGINE, M8 4
43 0205490100 NUT, CUSHION RUBBER, M10 8
44 0205490100 NUT, PUMP, M10 2
45 0451290100 SPRING WASHER, PUMP, M10 2
46 0401650080 WASHER, ENGINE, M8 4
47 0457290080 SPRING WASHER (VOLUTE CASING), M8 2
48 0451290080 SPRING WASHER (DRAIN COVER SET), M8 4
49 0451290100 SPRING WASHER (CUSHION RUBBER), M10 8
50 0451290080 SPRING WASHER (ENGINE), M8 4
51# 0458220080 SEAL WASHER 1
52 0451290080 SPRING WASHER (CASING COVER ), M8 4
53 0742214050 STRAINER 1
54 1889108050 CAP 1
55 0481310700 O’RING, G70 1
56 1889250770 OVERFLOW SUPPRESSOR 1
57 1B20 ENGINE, HATZ 1
58 KIT2T KIT, MECHANICAL SEAL, SLEEVE, & O-RINGS 1
