QP2TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #2(08/14/14) — PAGE 11
Table 1. Specifications (Pump)
Pump
Model QP2TZ
Type Trash Pump
Suction 2.0 in. (50 mm.)
Discharge Size 2.0 in. (50 mm.)
Maximum Pumping
Capacity
198 gallons/minute
(750 liters/minute)
Max. Solids Diameter 0.75 in. (19.1 mm)
Max. Head 95 ft. (29.0 m)
Max. Lift 25 ft. (7.62 m)
Max. Pressure 41.1 psi (283 kPa)
Dry Net Weight 130 lbs. (59 Kg.)
SPECIFICATIONS (PUMP)
Figure 1. QP2TZ Dimensions
21.8 IN.
(55.3 CM.)
17.2 IN.
(43.7 CM.)
25.7 IN.
(65.2 CM.)
