QP205SLT/QPT205SLT CENTRIFUGAL PUMP • OPERATION AND PARTS MANUAL — REV. #2 (05/16/14) — PAGE 33
NO. PART NO. PART NAME QTY. REMARKS
29 0105050820 BOLT M8X20 4
30 0105050845 BOLT M8X45..........................................................4............S/N 205SLT-0131 AND BELOW
30 0105050840 BOLT M8X40..........................................................4............S/N 205SLT-0132 AND ABOVE
31 0451250080 SPRING WASHER M8 4
32 0105050850 BOLT M8X50 1
33$ CAP, W/ WASHER .................................................1 ...........NOT SOLD SEPARATELY
34$ CAP, W/ WASHER .................................................1............NOT SOLD SEPARATELY
35$ CHAINS, CAPS ......................................................3............NOT SOLD SEPARATELY
36 1814209660ASSY BALL CHAIN W/CAPS ...........................................1............INCLUDES ITEMS W/ $
37 0451250080 SPRING WASHER M8 1
38 0205450080 NUT M8 1
39 0205450100 NUT M10 8
40 0205450100 NUT M10 4
41 0451250100 SPRING WASHER M10 4
42 0451250100 SPRING WASHER M10 8
43% 0451290060 SPRING WASHER M6 2
44 0105090640 BOLT M6X40 2
45 0181050825 BOLT WITH SPRING WASHER M8X25 6
46 0181050825 BOLT WITH SPRING WASHER M8X25 4
47 0191160625 BOLT 4
48% 0181050820 BOLT SET WITH SPRING WASHER .....................1............QP205SLT ONLY
48 0181090820 BOLT SET WITH SPRING WASHER .....................1 ...........QPT205SLT ONLY
49 0451250100 SPRING WASHER M10 4
50 0742303050 STRAINER 1
51 0105051045 BOLT 4
52 18672140210014 ENGINE BASE .......................................................1............REPLACES 18672140200014
53 * 0852834230 ADJUST LINER .....................................................1............QP205SLT ONLY
54 * 0852854230 ADJUST LINER .....................................................1............QP205SLT ONLY
55 0920312013 NYLON NET 1
56 KIT205SLT KIT, MECHANICAL SEAL, SLEEVE, O-RINGS .....1............INCLUDES ITEMS W/ *
QP205SLT ONLY
57 GX240K1PMT2 ENGINE, HONDA 8.0 HP ......................................1............S/N 205SLT-0049 AND BELOW
57 GX240U1PMT2 ENGINE, HONDA 8.0 HP ......................................1............S/N 205SLT-0050 TO 205SLT-0198
57 GX240UT2PMT2 ENGINE, HONDA 8.0 HP 1 S/N 205SLT-0199 AND ABOVE
58% 7207081300 LINER RING ..........................................................1............QPT205SLT ONLY
59 7207990510 CONVERSION KIT, IMPELLER ASSY. ..................1............INCLUDES ITEMS W/ %
NOTICE
Item 59, Conversion Kit, Part Number 7207990510, is
to upgrade a QP205SLT to a QPT205SLT pump.
PUMP ASSEMBLY
