QP205SLT/QPT205SLT CENTRIFUGAL PUMP • OPERATION AND PARTS MANUAL — REV. #2 (05/16/14) — PAGE 31
NO.
PART NO.
PART NAME
QTY.
REMARKS
1 1814100010 CASING
1
2
1814100160
SUCTION COVER, NPT 2"
1
3
1378350350
CHECK VALVE
1
4
1878060130
VOLUTE CASING 1 ...............................................1............QP205SLT ONLY
4%
7207060130
VOLUTE CASING 1 ...............................................1............QPT205SLT ONLY
5
1878000040
OPEN IMPELLER 2 ...............................................1............QP205SLT ONLY
5%
7207060040
CLOSED IMPELLER .............................................1............QPT205SLT ONLY
6
*
% 1878081290
LINER RING 2
1
7
1878060110
VOLUTE CASING 2 ...............................................1............QP205SLT ONLY
7%
7207060110
VOLUTE CASING 2 ...............................................1............QPT205SLT ONLY
8
1878060030
CLOSED IMPELLER 1 ..........................................1............QP205SLT ONLY
8%
7207060030
CLOSED IMPELLER 2 ..........................................1............QPT205SLT ONLY
9
1878060120
VOLUTE CASING 3 ...............................................1............QP205SLT ONLY
9%
7207060120
VOLUTE CASING 3 ...............................................1............QPT205SLT ONLY
10
43592012400011 IMPELLER WASHER 34 x 9 x 4.5T .......................1............QP205SLT ONLY
10% 7207251240
IMPELLER WASHER 30 x 9 x 5T ..........................1............QPT205SLT ONLY
11
1882221010
PUMP SHAFT
1
12
*
0803112930
MECHANICAL SEAL
1
13
1988100020
CASING COVER
1
14
1895214010P002 BASE
1
15
1803330360
DELIVERY COVER PACKING
1
16
43570006000014 CASING COVER SET PLATE
1
18
0631211100ASSY FLOODING CAP W/O-RING ............................. ....1 ...........INCLUDES ITEM W/ #
19#
0480350300
O-RING (FLOODING CAP), P30
1
20
0631211100ASSY DRAIN CAP W/O-RING .........................................1............INCLUDES ITEM W/ &
21&
0480350300
O-RING (DRAIN CAP), P30
1
22
*
0489352550
O-RING (CASING) DIA. 3.5 x 255
1
23
0723302040
CUSHION RUBBER
4
24
0510040443
KEY 1/4" x 1/4" x 43
1
25
1814100090
DELIVERY COVER (3-WAY OUTLET) ..................1............S/N 205SLT-0131 AND BELOW
25
1814100091
DELIVERY COVER (3-WAY OUTLET) ..................1............S/N 205SLT-0132 AND ABOVE
26
*
0482200750
O-RING (VOLUTE CASING)
1
27
0458220080
SEAL WASHER
4
28%
*
1803521220
LINER RING
1
PUMP ASSEMBLY
