PAGE 14 — MQ DRY PRIME PUMP • PARTS MANUAL — REV. #5 (10/12/2009)
DEUTZ F3L914 ENGINE ASSY. (1)
DEUTZ F3L914 ENGINE ASSY. (1)
1
1
2
USE THREADLOCK: HIGH TEMP.
LOCTITE BLUE 246 OR EQUIVALENT.
TORQUE TO 50 FT-LBF (67.9 N-m)
USE THREADLOCK: HIGH TEMP.
LOCTITE RED 272 OR EQUIVALENT
TORQUE TO 250 FT-LB (338.9 N-m)
1
2
1
16
6
12
11
3
13
10
15
1
4
14
7
8
9
2
5
