MVH150VGH • OPERATION AND PARTS MANUAL — REV. #1 (09/22/08) — PAGE 59
GX200U1SM12 — CARBURETOR ASSY.
1
16010ZE1812
GASKET KIT .............................................. 1 ................ INCLUDES ITEMS W/ #
2
*
16011ZE0005
VALVE SET, FLOAT
1
3
*
16013ZE0005
FLOAT SET
1
4
*
16015ZE0831
CHAMBER SET, FLOAT ............................. 1 ................ INCLUDES ITEM W/ $
4A
*
$#
GASKET, FLOAT CHAMBER SET ............. 1 ................ NOT SOLD SEPARATELY
5
*
16016ZH7W01
SCREW SET, PILOT
1
6
*
16024ZE1811
SCREW SET, DRAIN ................................. 1 ................ INCLUDES ITEM W/ %
6A
*
%#
GASKET, DRAIN SCREW SET .................. 1 ................ NOT SOLD SEPARATELY
7
*
16028ZE0005
SCREW SET .............................................. 1 ................ INCLUDES ITEM W/ @
7A
*
@#
GASKET, SCREW SET .............................. 1 ................ NOT SOLD SEPARATELY
8
*
16044ZE0005
CHOKE SET
1
9
16100ZL0W51
CARBURETOR ASSY. (BE64B B/C) .......... 1 ................ INCLUDES ITEMS W/
*
10
*
16124ZE0005
SCREW, THROTTLE STOP
1
11
*
16166ZL0000
NOZZLE, MAIN
1
12#
*
16173001004
PACKING, FUEL STRAINER CUP
1
13
16211ZL0000
INSULATOR, CARBURETOR
1
14
16212ZH8800
PACKING, INSULATOR
1
15
16220ZE1020
SPACER COMP., CARBURETOR
1
16
16221ZH8801
PACKING, CARBURETOR
1
19
16610ZE1000
LEVER COMP., CHOKE (STD.) ................. 1 ................ INCLUDES ITEM W/ +
23
*
16953ZE1812
LEVER, COCK
1
24
*
16954ZE1812
PLATE, LEVER SETTING
1
25
*
16956ZE1811
SPRING, COCK LEVER
1
26#
*
16957ZE1812
PACKING, FUEL COCK
1
27
*
16967ZE0811
CUP, FUEL STRAINER
1
29
*
93500030061H
SCREW, PAN, 3X6
2
32+
9430520122
PIN, SPRING, 2X12
1
33
99101ZH80680
JET, MAIN, #68, OPTION
1
33
99101ZH80700
JET, MAIN, #70, OPTION
1
33
*
99101ZH80720
JET, MAIN, #72
1
34
*
99204ZA00450
JET SET, PILOT, #45 ................................. 1 ................ INCLUDES ITEM W/ &
34A
*
&#
GASKET, PILOT JET SET #45 .................. 1 ................ NOT SOLD SEPARATELY
