Inspection and Maintenance Service Tables.
To make sure your plate compactor is always in good working
condition before using, carry out the maintenance inspection in
accordance with Tables 5 through 7.
Daily Service
Check for leakage of fuel or oil.
Check for loose screws including tightness. See Table 7
below (tightening torque ), for retightening:
Remove soil and clean the bottom of compaction plate.
