MVC80VH/VHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (1/13/11) — PAGE 47
CAMSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 12209ZH8003 SEAL, VALVE STEM 1
2 14100ZE1812 CAMSHAFT ASSY. ...................................... 1 ...... INCLUDES ITEMS W/ *
4 14410ZE1010 ROD, PUSH 2
6 14431ZE1000 ARM, VALVE ROCKER 2
7 14441ZE1010 LIFTER, VALVE 2
8 14451ZE1013 PIVOT, ROCKER ARM 2
9 * 14568ZE1000 SPRING, WEIGHT RETURN 1
10 14711ZF1000 VALVE, INLET 1
11 14721ZF0000 VALVE, EXHAUST 1
12 14751ZF1000 SPRING VALVE 2
13 14771ZE1000 RETAINER, IN. VALVE SPRING 1
14 14773ZE1000 RETAINER, EX. VALVE SPRING 1
15 14781ZE1000 ROTATOR, VALVE 1
16 14791ZE1010 PLATE, PUSH ROD GUIDE 1
17 90012ZE0010 BOLT, PIVOT (8MM) 2
18 90206ZE1000 NUT, PIVOT ADJ. 2
CAMSHAFT ASSY.
