MVC80VH/VHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (1/13/11) — PAGE 33
VIBRATOR ASSY.
NO PART NO PART NAME QTY. REMARKS
61 * 418117730 VIBRATING CASE 1
62 001221445 BOLT 14X45 T 4
63 030214350 WASHER, LOCK M14 4
64 031114260 WASHER, FLAT M14 4
65 * 418456950 CASE COVER/PULLEY 1
66 * 060403020 OIL SEAL TC-30458 1
67 * 418456960 CASE COVER/SHUT-OFF 1
68 * 418456970 PACKING 2
69 * 002400820 BOLT 8X20 SW, PW 8
70 418456990 COVER SEAL, VIB. 1
71 * 418343630 ECC. ROTOR SHAFT 1
72 * 040306307 BEARING 6307C3 2
72 * 040406307 BEARING 6307C4 2
73 * 418456981 PULLEY, VIBRATOR 1
74 * 951401920 KEY 7X7X30 1
75 * 952403450 WASHER 11X35X4.5 1
77 * 002211030 BOLT 10X30 H, SW 1
78 * 953400270 PLUG 1/4X14 10L 1
79 * 953405260 PACKING 1
80 418910110 VIBRATOR ASSY ...................................... 1 ................. INCLUDES ITEMS W/ *
VIBRATOR ASSY.
