MVC77 PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #4 (1/14/11) — PAGE 45
NO PART NO PART NAME QTY. REMARKS
1 11300ZZE1633 COVER ASSY. CRANKCASE ...... 1 ............ INCLUDES ITEMS W/ *
4 11381ZH8801 GASKET CRANKCASE 1
5 15600ZE1003 OIL GAUGE ASSY. ...................... 1 ............ INCLUDES ITEMS W/%
6 15600ZG4003 OIL PLUG ASSY. ......................... 1 ............ INCLUDES ITEMS W/#
8# 15625ZE1003 PACKING, OIL FILLER CAP 1
9% 15625ZE1003 PACKING, OIL FILLER CAP 1
13 * 91202883005 OIL SEAL 25X41X6 1
14 9430108140 KNOCK PIN 8X14 2
16 957010803200 FLANGE BOLT 8X32 6
17 * 961006205000 BALL BEARING 6205 1
HONDA GX160K1QX2 — CRANKCASE COVER ASSY.
