Vibrator/plate mounting assy – Multiquip MVC77 User Manual
Page 35
MVC77 PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #4 (1/14/11) — PAGE 35
NO
PART NO
PART NAME
QTY.
REMARKS
1
408105330
VIBRATING PLATE
1
46
012212035
BOLT 12X35 T ......................................... 9 ................ REPLACES 001221235
47
030212300
SPRING WASHER M12
9
48
031112230
PLAIN WASHER M12
9
30
408910010
VIBRATOR ASSY. ................................... 1 ................ SEE PAGES 36 AND 37
VIBRATOR/PLATE MOUNTING ASSY.
