AR13HA-R RIDE-ON ROLLER — INSPECTION
Before Starting
1. Read safety instructions at begining of manual.
2. Clean the
ROLLER
, removing dirt and dust, particularly the
engine cooling air inlet, carburetor and air cleaner.
3.
Check the air filter for dirt and dust. If air filter is dirty, replace
air filter with a new one as required.
4. Check carburetor for external dirt and dust. Clean with dry
compressed air.
5.
Check fastening nuts and bolts for tightness.
Engine Oil Check
1. To check the engine oil level, place the roller on secure level
ground with the engine stopped.
2. Remove the dipstick from its holder (Figure 7) and wipe it
clean.
3. Check the oil level shown on the dipstick (Figure 8).
Figure 7. Engine Oil Dipstick (Removal)
The
HONDA GX-610 engine used
on the AR-13H roller has an "
Oil
Alert System". This system will
automatically stop the engine in the
event of low oil level. ALWAYS be
sure to check the engine oil level
prior to starting the engine.
Figure 8. Engine Oil Dipstick Level
NOTE
4. If the oil level is low, remove the oil filler cap (Figure 9) and
fill to the safe operating level (max) as indicated by the
dipstick. Fill with recommended type oil as listed in Table 4.
Maximum oil capacity is 1.90 quarts (1.8 liters).
Figure 9. Engine Oil Filler Port
