PAGE 14 — AR13HA-R RIDE-ON TANDEM DRUM ROLLER — OPERATION & PARTS MANUAL — REV. #9 (06/28/11)
AR13HA-R RIDE-ON ROLLER — SPECIFICATIONS (ENGINE)
Table 2. Engine Specifications
Model Honda GX610K1QZB2/GX610R1QZB2 Engine
Type
Air-Cooled 4 Stroke, Overhead Valve, 2 cylinders (90
degree V-Twin), Gasoline Engine.
Piston Displacement 37.5 cu. in. (614 cc)
[Bore x Stroke] [3.03 in. x 2.60 in. (77 mm x 66 mm)]
Max. Output 18 hp (13.4 KW, 18.3 PS) at 3,600 rpm
Max. Governed Speed, No Load 3,500 rpm
Max. Torque 31.8 lbf-ft. at 2,500 rpm
Cooling System Forced Air
Engine Oil SAE-10W-30 for general use
Engine Oil Capacity (with oil filter
replacement)
1.90 qts. (1.80 liters)
Engine Oil Capacity (without oil
filter replacement)
1.59 qts. (1.50 liters)
Fuel Unleaded gasoline
Fuel Consumption 0.51 lb/hph (313 g/kWh, 230 g/PSh)
Spark Plug Type
NGK: ZGR5A
DENSO: J16CR-U
Idle Speed 1,400 +/- 150 rpm
PTO Shaft Rotation Counterclockwise
