DISPOSICIÓN DEL PANEL
1
2
3
MUD100.2
100 WATTS x2 RMS
2 CHANNEL AMPLIFIER
LEVEL
X-OVER
HI LOW
FULL
MA X
MIN
RED: 12V+
BLUE: REMOTE
BLACK: GND
WHITE: L+ BRIDGE+
WHT/BLK: L–
GREY: R+
GREY/BLK: R– BRIDGE–
MUD100.2
100 WATTS x2 RMS
2 CHANNEL AMPLIFIER
LEVEL
X-OVER
HI LOW
FULL
MA X
MIN
RED: 12V+
BLUE: REMOTE
BLACK: GND
WHITE: L+ BRIDGE+
WHT/BLK: L–
GREY: R+
GREY/BLK: R– BRIDGE–
