MTX Audio MUD100-2 200W RMS 2-Channel Power Sports Amplifier - Manual (Page 18)

M T X . C O M 18
DISPOSITION DU PANNEAU
1
2 3
MUD100.2
100 WATTS x2 RMS
2 CHANNEL AMPLIFIER
LEVEL X-OVER
HI LOW FULL
MA X MIN
RED: 12V+
BLUE: REMOTE
BLACK: GND
WHITE: L+ BRIDGE+
WHT/BLK: L–
GREY: R+
GREY/BLK: R– BRIDGE–
MUD100.2
100 WATTS x2 RMS
2 CHANNEL AMPLIFIER
LEVEL X-OVER
HI LOW FULL
MA X MIN
RED: 12V+
BLUE: REMOTE
BLACK: GND
WHITE: L+ BRIDGE+
WHT/BLK: L–
GREY: R+
GREY/BLK: R– BRIDGE–
