PRODUCT OVERVIEW
eng
5
X3‑40/X3‑45/X3‑55/X3‑70 MotorGuide Trolling Motor
CABLE STEER MODELS
a -
Directional indicator
b -
Mount bracket
c -
Battery cables
d -
Latch release handle
e -
Speed control
f -
Three‑position switch
g -
Foot pedal
h -
Serial number decal (under
the foot pedal)
i -
Momentary switch
j -
Propeller
k -
Lower unit
l -
Composite column
m -
Bracket door knob
a
h
b
c
d
e
f
g
i
j
k
l
m
54509
