Maximum Drilling Diameter
Gear Diameter
1st 6”
2nd 2-3/4”
3rd 1-1/2”
Load Speed 1st Gear 600 RPM
Load Speed 2nd Gear 1300 RPM
Load Speed 3rd Gear 2800 RPM
INSTRUCTIONS
AUXILIARY HANDLE
ELECTRIC SAFETY
GEAR SHIFTING
NOTICE:
ATTENTION:
The MK-130/3 is designed for wet drilling in concrete and stone using diamond core bits. For drilling
diameters bigger than 1-1/2” using 1st or 2nd speed, use a suitable drill stand.
In hand held drilling operations, only use the MK 130/3 with the enclosed auxiliary handle. This handle
must be tightened on the collar by turning the handle.
The MK-130/3 machine has class 1 protection. For operator protection this machine must only be
used with a GFCI.
Check that the voltage and frequency available are compatible with the drive motor. A ± 5% voltage
difference is allowed. For protection purposes the machine is equipped with a integrated GFCI switch
for the direct connection to a grounded socket. Check the GFCI before using the machine (please
read the separate instructions).
Choose the proper gear and speed according to the drill bit size used. To switch gears, turn drill
spindle by hand until gears mesh/align.
Use only a 3-wire extension cable with grounding conductor and sufficient cross-section (12 gauge
min.). A cross-section which is too small could lead to excessive voltage drop and to overheating the
motor and the cable.
Don’t use the GFCI-switch for switching the machine ON/OFF.
Switch only when the machine is stopped and turned OFF.
Hand Drilling in 1st gear is strongly not recommended as the high torque created
can be extremely dangerous and cause injury.
MK-130/3 OPERATION
CAUTION
The operator is responsible for all damages which may arise due to improper use.
