8
General Specifications
Motor 120V
Watts 1700
Frequency 40-60Hz
Speed 3 speed
Bit Capacity 3” (76mm) hand-held
6” (152mm) rig mounted
Connecting Threads 1-14” - 7” UNC
5/8” - 11 UNC
G1/2”
Weight 16 lbs. (7.2 kg)
Includes • Quick Release Water Valve
• GFCI
• Plastic Carrying Case
Part # 158368
PRODUCT SPECIFICATIONS
Ideal for drilling holes in floors, walls, ceilings and for all concrete anchoring systems. Fast and effi-
cient drilling of reinforced concrete, concrete, brick, block and stone.
5. Don’t use the machine if a part of the housing is damaged or in case of damages on the switch,
cable or plug (check it every day).
6. When using the drill, cooling water is not allowed to get into the motor or any electrical parts.
7. Stop working if water is dripping out of the overrunning bore hole and take the machine to an
authorized service center.
8. Overhead-drilling should be done with using suitable safety measures (water collection).
9. After a breakdown, the machine should only be switched on again if the drill bit can be turned.
10. Before starting your work, check that the Ground Fault Circuit Interrupter (GFCI) is functioning
properly by pressing the test button. The GFCI must never lay in the water.
11. When using the machine with manual control always hold it with both hands and take up a safe
position. Pay attention to the reaction torque of the machine.
12. If drilling through ceilings, secure the place below, because the core may fall downward.
MK-130/3 PRODUCT SPECIFICATION
