Mk-sdg parts list – MK Diamond MK-SDG User Manual
Page 23
23
GD17 Gasket, 30A Switch Box
1
159491
GD18 Seal, Level, 30A Switch Box
1
159492
GD19 Lever, On/Off, 30A Switch Box
1
159490
GD20 Washer, #10 SAE Flat
1
154369
GD21 Washer, Lock, IT, #10
1
158336
GD22 Screw, Pan Head #10-24 x 5/16
1
159494
GD23 Screw, Flat Head 6-32 X 5/16
6
159493
GD24 Switch, 30Amp Motor Controller
1
159488
GD25 Plate, Mounting, Switch
1
159489
GD26 Box, 30A Switch
1
159487
GD27 Connector, Cord LTF29
1
160689
GD28 Nut, MCFL, 1/2NPT
1
152729
GD29 Bracket, MK 212 Switch
1
159864
GD30 Screw, Pan Head Phillips 1/4-20 x 1/2
2
155452
GD31 Washer, Lock, Split, 1/4
2
152591
GD32 Screw, Hex Head Cap 5/16-18 x 3/4
2
151369
GD33 Washer, 5/16 Flat SAE
4
151754
GD34 Washer, 5/16 Split Lock
2
151747
GD35 Nut, 5/16-18 Hex
2
101196
GD36 Label, Control Panel, SDG Elect
1
160046
H
Assembly, Axle
H1
Wheel, 10”Dia. x 2.5”
2
157889
H2
Cotter Pin, Steel Hairpin, 5/8”- 3/4” x .148” x 2 11/16”
2
158228
H3
Axle, 5/8” Dia.
1
157887
H4
Washer, 5/8 SAE Flat
4
158350
J
Assembly, Handlebar
J1
Handlebar
1
157786
J2
Handgrip, .875 x 4.25 Neoprene
2
229413
J3
Screw, 3/8-16 X 2 Hex Head Cap
2
153485
J4
Washer, 3/8 SAE Flat
4
150923
J5
Nut, 3/8-16 Nylock Hex
2
152505
K
Assembly, Throttle, Honda
K1
Screw, 10-24 X 1/2” Pan Head Phillips Cap
2
151744
K2
Nut, 10-24 Clip
2
155407
K3
Assembly, Throttle Head
1
155406
K4
Cable, Throttle, Honda
1
156640
L
Assembly, Water Valve
L1
Fitting, Brass, 1/2 MNPT x Garden Hose Swivel
1
151322
L2
Valve, Shut-Off, 1/2 FNPT x 1/2 FNPT
1
150843
L3
Nut, 1/2 NPT
1
152729
L4
Fitting, Brass, 1/2 MNPT x 1/4 Compression Fit
1
157563
L5
Tube, ¼ OD Water
2’
157564
L6
Clamp, 5/8 Hose
2
151198
L7
Hose, Water Vinyl 1/4 x 3/8
6’
132951
MK-SDG PARTS LIST
