12
PRODUCT SPECIFICATIONS
The MK-SDG is a versatile unit. Operated and used according to this manual, the MK-SDG
will provide years of dependable service.
FEATURES
SPECIFICATIONS
• Uses either a 10 or 20 segment 10" diameter diamond grinding discs to level, smooth or
clean the top surface of concrete slabs. (A)
• Provides a smoother finish compared to other methods such as scarifiers or scabblers.
• Two-position wheel carriage for grinding and easy transport. (B)
• Front taper for enhanced visibility.
• Removable nose weight and handle for easy transportation. (C)
• Dust shroud helps contain grinding debris.
• Works on concrete slabs, terrazzo, brick, stone and ceramic tile floors.
Specifications for the MK-SDG are listed in the table below.
Model MK-SDG-11 MK-SDG 3
Engine Honda Baldor / Leeson
Power GX340 3 HP
Disc RPM 980 980
Disc Capacity 10" (254mm) 10" (254mm)
Ballast 70 lbs. (32kg) 70 lbs. (32kg)
Weight 212 lbs. (96kg) 212 lbs. (96kg)
LxWxH (inches) 40” x 16” x 42” 40” x 16” x 42”
LxWxH (mm) 1016 x 406 x 1066 1016 x 406 x 1066
Part # 157377 161180
A B C
MK-SDG PRODUCT SPECIFICATIONS
