MK-100 TRACKER Revision 02/03, Effective Date February 12, 2003 Page 41
EXPLODED VIEW AND PARTS LIST
Item Description Qty Part #
F-J Assembly, 115V Cutting Head, MK-100 1 158225
F Belt Guard n/a
F1 Belt Guard, MK-100 (comp)
Belt Guard, MK-100 logo (raw)
Insert, 3/8-16 AVK 1
1
2 158319-00
158318-00
158193
F2 Bracket, Inner Belt Guard, 100/101/101Pro 1 158611
F3 Screw, 1/4-20 x 3/4 Hex Head Cap 3 152370
F4 Screw, 1/4-20 x 1 Hex Head Cap 1 152676
F5 Washer, 1/4 Split Lock 4 152591
F6 Washer, 1/4 SAE Flat 4 151915
F7 Belt, 260J6 Micro-V 1 158194
F8 Knob, 3/8-16 X 1.5 MK Adjustment 1 156770-2
F9 Washer, 3/8 SAE Flat 1 150923
G Blade Guard 1 n/a
G1 Blade Guard, 101/115 (comp)
Blade Guard, MK logo (raw) 1
1 153659
152508
G2 Elbow, 1/8 MNPT X 1/4 BARB 90
° Brass
1 154652
G3 Tube, Water
Tubing, Stainless Steel 1/4 OD X .028 wall
2
.75‘
155389
152579
G4 Screw, 5/16-18 X 1/2 Socket Head Set 3 152607
G5A Label, Tile saw Serial #, No Mark 1 157249-01
H Subassembly, 115V Cutting Head, MK-100 1 158191
H1 Head, 10” Cutting (comp)
Head, 10” Cutting (raw) 1
1 158224
158223
H2 Pin, Blade Shaft Lock 1 158200
H3 Spring, Blade Guard Lock 1 158201
H4 E-Ring, 1/4 Retaining 1 158202
H5 Bearing, 17mm X 40mm X 12mm Ball (6203-2NSE) 2 137711
H6 Shaft, Blade 880/101/1080
Steel, 3/4 Dia C12L14 1
1’
158222
154188
H7 Flange, 2-3/8 Inner
Steel, 2-3/8 Dia C12L14 1
.09’
137737
154196
H8 Flange, 2-3/8 Outer 1 135830
H9 Nut, 5/8-18 Hex 1 135848
H10 Pulley, 6J19 X 5/8 Bore
Steel, 2.0 Dia C1215 CD 1
1.5”
158199
154723
H11 Key, 3/16 x 3/16 x 1 1/8 Square 1 150344
H12 Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point 2 157083
H13 Bumper, 1/2 Dia Rubber 1 152674
H14 Screw, 5/16-18 X 1 Hex Head Cap 4 151743
H15 Washer, 5/16 SAE Flat 4 151754
H16 Washer, 5/16 Split Lock 4 151747
H17 Nut, 5/16-18 Hex 4 101196
H18 Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread 1 151748
H19 Pivot, Blade Guard 1 153208
H20 Washer, 3/8 SAE Flat 2 150923
H21 Wingnut, 5/16-18 Nylock 1 151746
H22 Strap, Motor Adjustment 1 152673
H23 Screw, 3/8-16 X 3 1/2 Hex Head Full Thread 1 153147
