- 3 -
Fig. 1: 8” LX200 Telescope.
1. Viewfinder Dew Shield
2. Viewfinder Collimation Screws
3. Declination (Dec) Setting Circle
4. Declination Pointer
5. Focus Knob
6. Eyepiece Holder
7. Right Ascension (R.A) Lock
8. Right Ascension Slow-Motion Controls
9. Right Ascension Vernier Pointer 10. Right Ascension Setting Circle
11. Power Panel
12. Keypad Hand Controller
13. Diagonal Mirror
14. Eyepiece
15. Bubble Level
16. Hour Angel (HA) Pointer
17. Drive Base
18. Viewfinder Focus Lock Ring
Captions for Figure 1
✵
WARNING!
✵
Never use the LX200 telescope to look at the Sun! Looking at or near the Sun will cause instant
and irreversible damage to your eye. Eye damage is often painless, so there is no warning to the
observer that damage has occurred until it is too late. Do not point the telescope or its viewfinder
at or near the Sun. Do not look through the telescope or its viewfinder as it is moving. Children
should always have adult supervision while observing.
1 18 2
14
13
5 6
12
3
4
7
8
9
10
11
15
16
17
