MBT Lighting LEDSAUCER - Manual (Page 2)

Features
Voltage: AC100-240V 50Hz/60Hz
Power: 50W
Light source: 3pcs 3*3W tricolor LED
Control modes: Auto running, Sound active, DMX 512, Master and slave.
Channels: 8 channels DMX512
4-button LED DMX display
Package size: 28cm*28cm*39cm
Weight: 6.5KG
Display instruction
MODE/ESC UP DOWN ENTER Function
Aut1 Auto Single mode invalid Single mode invalid
Display Auto
after enter
Auto mode
Sound Sound Single mode invalid Single mode invalid
Display
Sound after
enter
Sound active
A001-A512 Addr Display secondary
menu when press
this button +1
Display secondary
menu when press
this button +1
Display
Address
after enter
DMX512
Sla Stau Single mode invalid Single mode invalid
Display Stau
after enter
Slave mode
DMX control
Channel Data Control
0-254 X stalk (0º-360º)
CH1
255 Sound control
CH 2 0-255 X stalk speed (0-255 quick to slow)
CH 3 0-255 Y stalk (0º-180º)
CH 4 0-255 Y stalk speed (0-255 quick to slow)
0-99 Z stalk turn clockwise
100-154 Stop CH 5
250-255 Z stalk turn reverse
CH 6 0-255 Z stalk speed (0 quick -255 slow)
0-41 Black out
42-83 Color R R R
84-125 Color G G G
126-167 Color B B B
168-209 Color R G B
210-241 Color G B R
CH 7
242-255 Color B R G
CH 8 0-255 Strobe speed (0 quick -255 slow)
Notice:
When gobos programming, do not turn on all the LED lights for a long
time to ensure the stability and lengthen the lifetime of the products.
Please make sure disconnect the power when do not use
