MBT Lighting LEDSMARTSCAN (SRS-7001) - Manual (Page 4)

Channel 4- Gobos
Value
Feature
0 7 OPEN
8 14 Spin Gobo 1
15 21 Spin Gobo 2
22 28 Spin Gobo 3
29 35 Spin Gobo 4
36 42 Spin Gobo 5
43 49 Spin Gobo 6
50 56 Spin Gobo 7
57 63 Spin Gobo 8
64 70 OPEN SHAKE
71 77 GOBO 1 SHAKE
78 84 GOBO 2 SHAKE
85 91 GOBO 3 SHAKE
92 98 GOBO 4 SHAKE
99 105 GOBO 5 SHAKE
106 112 GOBO 6 SHAKE
113 119 GOBO 7 SHAKE
120 127 GOBO 8 SHAKE
128 255 GOBO WHEEL ROTATION
SLOW-FAST
Channel 5- Shutter/Strobe
Value Feature
0 7 Blackout
8 15 Shutter open
16 131 Strobing slow-fast
132 139 Shutter open
140 180 Shutter slow open-fast close
181 189 Shutter open
190 231 Shutter fast open-slow close
232 239 Sutter open(235 reset-after
3-5seconds)
240 247 Random strobe
248 255 Shutter open
Channel 6- Dimmer
0
255 Dimmer
Channel 7-Moving head movement
Value Feature
0 7 No function
8 25 Movement 1
26 43 Movement 2
44 61 Movement 3
62 79 Movement 4
80 97 Movement 5
98 115 Movement 6
116 133 Movement 7
134 151 Movement 8
152 169 Movement 9
170 187 Movement 10
188 205 Movement 11
206 223 Movement 12
224 241 Movement 13
242 255 Movement 14
