Features
Voltage: AC100-240V 50/60Hz
Power: 25W
144pcs(30R, 30G, 30B ,30A, 24W) intensive brightness LEDs
3CH/12CH DMX channels
1. Digital displays
1. Press 1. MENU (display ADDR): A001-A512
2. CHND (choose channel):3CH/12CH
3. SLND (choose master/slave1/slave2): NAST is master, SLV1,SLV2
4. SHND (choose effect):
A. SOUN (sound control), press DOWN to confirm
B. COLO (color changing. COL1 to COL31), press DOWN to confirm
AUTO (speed SP01-SP08)
C. FADE, gradually color changing (speed SP01-SP08)
5. MANU (manual change color) RED (0-255)
GREEN (0-255)
BLUE (0-255)
AMBER (0-255)
WHITE (0-255)
6. TEST (color test)
7. FHRS: (using time of light)
2. DMX operation
3-Channel mode
DMX channel
Function & Value
0-15 black out
Channel 1 Brightness
16-255 from dark to bright
0-15 black out
Channel 2 Strobe
16-255 strobe speed
0 black out
1-120 color
Channel 3 Color+color
changing auto
run
121-255 auto run and speed
12-Channel mode
DMX channel
Function & Value
0-15 black out
Channel 1 Brightness
16-255 from dark to bright
0-15 black out
Channel 2 Strobe
16-255 strobe speed
0 black out
Channel 3 Red dimmer
1-255 red dimmer
0 black out
Channel 4 Green dimmer
1-255 green dimmer
0 black out
Channel 5 Blue dimmer
1-255 blue dimmer
0 black out
Channel 6 Amber dimmer
1-255 amber dimmer
0 black out
Channel 7 White dimmer
1-255 white dimmer
0-15 black out
Channel 8 Color mixation
16-255 color mixation
0 black out
Channel 9 Color mixation
speed
1-255 color speed
0-15 black out
Channel 10 Color change
gradually 16-255 choose color change
0-15 black out
Channel 11 Color
gradually
change speed
16-255 color gradually change
speed
0-15 black out
16-255 controller sound active
Channel 12 Sound active
1-255 red dimmer
