MB QUART QUB Polaris - Manual (Page 6)

P/N 9925685 Rev 01 09/14 Page 6 of 8
9. Re-install upper pod (G) by fastening three screws removed in Step 2.
Tighten screws to torque 10 in-lbs. (1.13 Nm).
8. Snap fit bluetooth speaker (4) and strap (8) on to the
audio mount bracket assembly as shown in figure.
6. Align and Install audio mount bracket assembly on
the pod using two tuflok rivets (12) as shown in
figure.
7. Use rubbing alcohol, pledge or other temporary
lubricant on the rubber gasket, both sides.
Push back bezel and cluster assembly (F) to fix onto
the upper pod as shown in figure.
F
12
4
8
