Mayline 120 Degree Starter User Manual

Assembly instructions transaction 120° starter, Components, Hardware bag (part no. a8146)

background image

When ordering components, specific color and/or size information may be required.

Contact a Mayline Customer Service Representative. 1-800-822-8037

NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.

COMPONENTS:

Item # QTY. DESCRIPTION PART #

1 3 LEG

A8043**

2 3 BEAM ASSEMBLY

A8139**

3 6 TROUGH SIDE

B8438**

4 3 PAN

B8439**

5

1 CORNER CONNECTOR Call~~**

6 3 WORK SURFACE

Call~~**

ASSEMBLY INSTRUCTIONS

TRANSACTION 120° STARTER

Item # QTY. DESCRIPTION PART #

7 0/12 ACCESS PANEL

L7006**

8 3 CENTER ACCESS PANEL L7286**

9

3

OUTER LEG PANEL B8258**

10 3 INNER LEG PANEL B8219**

11

3

CORNER CONNECTOR

INNER LEG PANEL B8440**

** Denotes Color Code

~~Denotes Size

HARDWARE BAG (PART No. A8146)

* for individual item, order that part number

Item # QTY DESCRIPTION PART #

E1

6

TUBE INSERT, 5/16-18

T139*

E2

6

GLIDE

Q608*

E3

3

GLIDE

Q630*

E4 38

SCREWS #10-32 x 1/2"

X204*

E5 12

WASHER, EXT STAR #10

W38*

E6 44

SCREW #10 x 3/4

X11*

E7

7 PLUG, SQUARE HOLE

F782*

E8

6 SLAM LATCH

Q643*

E9

9 BUSHING

F764*

E10

18 RATCHET FASTENER F483*

E11

12 PINE TREE CLIP

F529*
