Mayline Technology Beltway User Manual
Mayline Furniture
PRINTED IN USA
1
6/1 2
I766
TECHNOLOGY BELTWAY EZTB**
1 . Push the ends of the table together.
Leave a gap between the tops to accept
the Beltway.
2. Set the Beltway betwe
e
n the two
tables and slide the tables firmly against
the Beltway.
Lip
Note:
Make sure the table is pushed firmly
against the Beltway, and the lip is
resting on the top of the worksurface.
G
F
E
D
C
B
A
ITEM QTY DESCRIPTION
A
4
BLANK DATA CUTOUT COVER
B
8
#1 0 X 3/4 PHILLIPS PAN HEAD PARTICLE
BOARD SCREW
C
2
3/8-1 6 X 1 .5 PHILLIPS TAPERED HEAD
MACHINE SCREW
D
2
NYLON INSERT LOCKNUT, 3/8
E
4
GROMMETS
F
2
HOLE COVERS
G
2
WIRE CLAMPS
Leg
Gusset
Table Top
Beltway
