1. Separate the Drawer Slides (10) into two pieces. Extend the
Slide to the full extension. Remove the smaller portion (10B) by
pressing the plastic release and pulling.
2. Attach the large Slide portion (10A) to the Center Support (9)
using two Screws (E16). Begin attaching the Slide using the large
'Horizontal' slot in the last mounting tab.
3. Attach one large Slide portion (10A) to the brackets on the R.H.
side of the table using two Screws (E16). Begin attaching the
Slide using the large 'Horizontal' slot in the last mounting tab.
4. Attach the smaller Slide portion (10B) to each side of the
Drawer body using three Screws (E17) and three Acorn Nuts
(E18). Begin attaching the Slide using the 'Vertical' slot in the first
hole cluster.
5. Install the Handle (E15) onto the Tool Drawer head using
Screws (E13).
6. Install the assembled Center Support into the Base. Attach the
Support with two Screws (E13) and two Nuts (E14) per rail.
7. Install the drawer into the assembled table.
