Mayline TechWorks Corner User Manual
Assembly instructions techworks corner tables
REF. # QTY. DESCRIPTION PART No.
E1 18 1/4-20 X 1/2 SCREW X352*
E2 5 GLIDE Q588*
E3 12 5/16-18 X 3 1/2 SCREW X241*
E4 8 5/16-18 X 3/4 SCREW X410*
E5 20 5/16-18 HEX NUT T130*
E6 20 LOCK WASHER W77*
E7 4 HOLE PLUG F639*
HARDWARE BAG (PART No. A7163)
*for individual item, order that part number
ASSEMBLY INSTRUCTIONS
TechWorks Corner Tables
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
REF. # QTY. DESCRIPTION PART No.
1 1 TOP CALL~~**
2 2 SPREADER CALL~~**
3 2 UPPER LEG ASSEMBLY A7104**
4 2 LOWER LEG ASSEMBLY A7603**
5 1 UPPER CORNER LEG A7134**
6 1 LOWER CORNER LEG A7135**
** Denotes Color Code
~~Denotes Size
