3
®
Part 2 – Remote configuration
This must be made using a remote connection (network or dial-up modem/ISDN).
It allows fine tuning of the Part 1-local configuration items, plus the creation of
multiple user accounts and declaration of all host computers.
Configuration
You can configure the Wizard IP and ServSwitch Duo IPC devices in any order,
however, when your local monitor, keyboard and mouse are connected to the
Wizard IP, it is that device that you will see first. In such cases, start with the
Wizard IP.
SERVSWITCH DUO IPC
Configuration Menu
Functions
Routing status
User Preferences
Global Preferences
Setup Options
Edit Computer List
Edit User List
Edit Autoscan List
Enter-Select
F1-More menus
Esc-Quit
Firmware Version 2.08
SERVSWITCH DUO IPC
Computer Port
Computer 1 01
Computer 2 02
Computer 3 03
Computer 4 04
Computer 5 05
Computer 6 06
Computer 7 07
Computer 8 08
User port 1 Status
ADMIN SHARED USE
F1-More menus F3-Find
Esc-Quit F4-Logout
Wizard IP
Wizard IP has a two-part initial configuration:
Part 1 – Local configuration
This must be carried out using the locally connected keyboard and monitor.
It prompts you to set up key basic details, network essentials, modem/ISDN
parameters and security key creation.
Wizard IP Unit Config
Hot Keys Ctrl+Alt
Screensaver
Time
Encryption
Date
10 mins
21
Prefer Off
15
27
Apr 31
2004
Next
: :
Unit Name
UK
Admin Passwd
Firmware Version BB2
Keybd Layout
Hardware Rev 1
Screen 1 of 5 Next
Wizard IP Network Config
Net Mask 255.255.255.0
192.168.42.154
No
Gateway
VNC Port
HTTP Port
5900
80
IP Address
00:0F:58:00:00:04
Use DHCP
MAC Address
Screen 2 of 5
> >
Ne
Wizard IP Modem Confi
ATZHS0=1
192.168.3.1
192.168.3.2
115200
Initialize P
Restore Defa
Init String
Baud Rate
Server IP
Client IP
Screen 3 of 5
See Part 1 - Local configuration
See Part 2 - Remote configuration
ServSwitch Duo IPC
The ServSwitch Duo IPC configuration can be carried out from the local
keyboard and monitor, connected to either the Wizard IP or to the ServSwitch
Duo IPC. The advantage of the former is that you can gain access to either
device from the same position. Once the Wizard IP is initially configured, you can
even configure the ServSwitch Duo IPC via a remote link.
See Overall initial configuration
The important aspects to configure are:
• Enable security
• Set admin user password
HT
Important
Individually the Wizard IP and ServSwitch Duo
IPC can both maintain their own separate
records of computers and users. However,
when used together, the ServSwitch Duo IPC
operates strictly as a slave to the Wizard IP. This
means that almost all configuration of users
and computers need only take place on the
Wizard IP. The exception to this is the creation
of a unique password for the ServSwitch Duo
IPC admin user.
You do not need to configure any users
or computers on the ServSwitch Duo IPC
unless, a local user, connected directly to
the ServSwitch Duo IPC, will need to access
computers.
The important aspects to configure
are:
•
Security considerations
• Register all host computers
• Register all users and define
which hosts computers to which
they will have access.
