Control of many hosts
On its own, the ServSwitch Duo
IPC provides access to either eight
(model ACR6208A) or sixteen (model
ACR6216A) host systems. However,
when linked to other KVM switches
(ServSwitch Duo IPC or otherwise) the
user(s) can easily control up to 128
separate host systems.
Optional power control
One or more optional power switches can be
attached to either unit. These control the supply
to the host system(s) and allow the remote user to
hard reset any system that has suffered a failure.
Remote control
The Wizard IP allows direct connection to
an Ethernet-based local network and from
there onto the wider Internet, as required.
The robust Wizard IP security system will also
allow direct connection to the Internet.
Local control
Both the Wizard IP and
ServSwitch Duo IPC provide
ports to allow local user
control, when required.
Welcome
Introduction
This guide is intended as a brief overview to using
the Wizard IP and the ServSwitch Duo IPC products
together. Both of these products are supplied with
their own dedicated guides and this overview
provides clickable links to those guides (when their
files are stored in the same folder of your system).
The Wizard IP and ServSwitch Duo IPC are both
powerful and popular products in their own rights.
However, when they are combined, the resulting
system is even greater than the sum of its parts.
Together these products equip you with full control
of multiple host computers from literally anywhere,
all via a basic internet connection.
HT
This overview guide contains three main sections:
Installation
Configuration
Operation
