PRO MIXER VMX100

3. REAR PANEL

The GND connection allows grounding of a turntable.

Use the AMP output to connect the VMX100 to an amplifier. The level is controlled by the MAIN knob in

the MIC/MAIN section.

In order to avoid power-up thumps, which can damage your loudspeakers, please power up

your amplifier last. There should be no signal present, e.g. no music playing, when you turn

on your amp. In addition, we suggest that you set all volume-related controls to zero (down)

before powering up your system. Following these precautions will save you from unpleasant

and potentially dangerous surprises.

The TAPE output enables you to record your performance by connecting a tape deck, DAT recorder etc.

Unlike the AMP output, the TAPE level is fixed, so that you have to adjust the input level on the recorder.

The POWER ON switch turns on the PRO MIXER.

FUSE HOLDER/VOLTAGE SELECTOR. Before you connect the equipment to an AC outlet, please be

sure that the voltage displayed corresponds with your local AC voltage. If you should need to replace the

fuse, be sure to replace it with one of the same type and value. Some units allow you to switch between

230 V and 115 V by rotating the fuse holder.

To operate the unit at 115 V, you must install a fuse with the double ampere rating.

This is the socket for the power cable. The impulse behavior of any given amplifier circuit depends

largely upon the power supplys inherent reserves. All mixers contain numerous operational amplifiers

(op-amps) for processing line-level signals. Due to the restricted performance of their power supplies,

many mixers show stress symptoms when used under extreme conditions, resulting in inferior audio

quality. Thanks to its generously proportioned power supply, this will never happen to your VMX100: The

sound will always be clear, transparent and powerful.

SERIAL NUMBER. Please take the time to fill out and return the warranty card within 14 days after the

date of purchase. This will entitle you to all the benefits of our extended warranty. Alternatively, you can
