EPAK 2500R AMPLIFIER / CONTROLLER
SPECIFICATIONS
5
High Frequency Amplifier Specification
Type Class AB Push-Pull low inter-modulation
Mosfet design with transformer
balanced output
Rated Continuous Power 100W
Distortion <0.05%
Operating Bandwidth 2.5kHz - 28kHz
Mid Frequency Amplifier Specification
Type Class AB Push-Pull low inter-modulation
Mosfet design with transformer
balanced output
Rated Continuous Power 200W
Distortion <0.05%
Operating Bandwidth 500Hz - 2.5kHz
Mid-Bass Frequency Amplifier Specification
Type High efficiency, Low frequency, Current-
enhancing switch mode
Rated Continuous Power 600W
Distortion <0.05%
Operating Bandwidth 130Hz - 500Hz
Low Frequency Amplifier Specification
Type High efficiency, Low frequency, Current-
enhancing switch mode
Rated Continuous Power 1600W
Distortion <0.05%
Operating Bandwidth 20Hz - 130Hz
Speaker Input
Speaker Input - / EP6 (Mid-Hi), EP4 (Sub)
Signal Input
Input Sensitivity 1.0V RMS
Input Impedance 20kΩ or 50Ω "Line Driver ready"
Power Requirements
Power Connector Neutrik PowerCon®
Operating Voltage 100-120V@60Hz | 205-240V@50Hz | 225-
260V@50Hz
Recommended Amperage 20A 115V | 10A 230V | 10A 250V
Physical Dimensions
Height 177.8mm (7.0")
Width 483mm (19.0")
Depth 495mm (19.5")
Weight 30kg (66lbs)
