VHD2000 AMPLIFIER / CONTROLLER
SPECIFICATIONS
Output Channels
Number of Channels 1
High Frequency Amplifier Specification
Type Class AB Push-Pull low IM Mosfet design, transformer
balanced output
Rated Continuous Power 300W
Distortion < 0.05%
Operating Bandwidth 2.2kHz ÷ 30kHz
Mid Frequency Amplifier Specification
Type High Efficiency, High power bandwidth
Rated Continuous Power 1000W
Distortion < 0.05%
Operating Bandwidth 450Hz ÷ 2.2kHz
Mid-Bass Frequency Amplifier Specification
Type High efficiency, Low frequency, Current-enhancing switch
mode
Rated Continuous Power 1600W
Distortion < 0.05%
Operating Bandwidth 100Hz ÷ 450Hz
Signal Input
Input Sensitivity 1.0V RMS
Input Impedance 10kΩ ÷ 50Ω "Line driver ready"
Signal Output Main Through OUT, Sub A and B OUT
Insert Mid/High, A Sub, B Sub
Speaker Output
Speaker Output - / EP6
Features
Level Control +/- 6dB
Subwoofer Level Control Sub A +/- 6dB, Sub B +/- 6dB
System setup 6x
Full Range Mode VHD2.0: 60Hz÷22kHz, Sub MUTE
Two per Side switch Double system - EQ
Power
Power Connector Neutrik PowerCon®
Operating Voltage 115V / 230V / 250V
Operating Voltage Range 100÷120V@60Hz | 205÷240V@50Hz | 225÷260V@50Hz
Recommended Amperage 20A 115V | 10A 230V | 10A 250V
Soft Start YES
Protection Thermal breaker
Physical Dimensions
Height 177.8mm (7.0")
Width 483mm (19.0")
Depth 495mm (19.5")
Weight 30kg (66lbs)
