KV2 Audio ESP2000 User Manual
Page 10

ESP2000
Specifications
Page | 10
System Acoustic Perfomance
-1dB Response
3Hz ÷ 40kHz
Channel Crosstalk
>70dB
Signal to Noise Ratio
>115dB
Total Harmonic Distortion
<0.005% (1W) / <0.01% (clip -1dB)
Output Channels
Amplifier Type
High Efficiency, Emitter coupled
Number of Channels
2
Total Output Power
2000W
Max. Output Voltage
78V (peak)
Max. Output Current
48A (peak)
Minimum load impedance per channel
2Ω
Out. Power 16Ω - 1 channel / 2 channels loaded
175W / 160W (RMS)
Out. Power 8Ω - 1 channel / 2 channels loaded
340W / 300W (RMS)
Out. Power 4Ω - 1 channel / 2 channels loaded
600W / 500W (RMS)
Out. Power 2Ω - 1 channel / 2 channels loaded
1000W / 800W (RMS)
Out. Power 16Ω - bridged
600W (RMS)
Out. Power 8Ω - bridged
1000W (RMS)
Out. Power 4Ω - bridged
1500W (RMS)
Signal Input
Input Channels
XLR
Input Sensitivity
1.55V
Input Impedance
20kΩ (balanced)
Signal Output
XLR Through
Speaker Output
Speaker Output
Neutrik Speakon®, 2x Binding posts
Features
Level Control
-∞ ÷ 0dB
Subwoofer Level Control
+6dB @ 60Hz
RMS Limiter
On / Off
Indicators
Power ON/Thermal, Signal/Limiter
Power
Power Connector
Neutrik PowerCon®
Operating Voltage
115V / 230V / 250V, (50 / 60Hz)
Recommended Amperage
10A 115V | 6A 230V | 6A 250V
Soft Start
YES
Protection
Thermal breaker
Cooling
2x temperature controlled fans
Physical Dimensions
Height
88mm (3.5"), 2RU
Width
483mm (19.00")
Depth
496,4mm (19.54")
Weight
16kg
