STEP 6
Refer
to
PIC 9. Position the cover assembly on the ignition
bracket . The three studs will fit in the three slots in the ignition
bracket.
STEP 7
Refer
to
PIC 10. Attach the cover to the ignition bracket from the backside
with the three included M6 nuts. Leave the nuts loose until all three have been
started; align the cover with the ignition switch face, then tighten the nuts.
Ride On!
BAHN LEFT IGNITION COVER for VICTORY — CHROME
INSTALLATION
PIC 9
IGNITION
SWITCH FACE
It is the end user’s responsibility to ensure that all of the fasteners
(including pre-assembled) are tightened before operation of the motorcy-
cle. Küryakyn will not provide warranty coverage on products or compo-
nents lost due to improper installation or lack of maintenance. Periodic in-
spection and maintenance are required on all fasteners.
Key chains and fobs coming in contact with the cover will
eventually damage the finish.
PIC 10
IGNITION
SWITCH FACE
M6 NUT
