INSTALLATION

CUSTOMER SERVICE

877.370.3604 (toll free)

INSTALLATION QUESTIONS

[email protected]

or call 715.247.2983

LIMITED WARRANTY

Küryakyn warrants that any Küryakyn products

sold hereunder, shall be free of defects in

materials and workmanship for a period of one

(1) year from the date of purchase by the

consumer excepting the following provisions:

Küryakyn shall have no obligation in the event

the customer is unable to provide a receipt

showing the date the customer purchased the

product(s).

The product must be properly installed,

maintained and operated under

normal conditions.

Küryakyn makes no warranty, expressed or

implied, with respect to any gold plated

products.

Küryakyn shall not be liable for any

consequential and incidental damages, including

labor and paint, resulting from failure of a

Küryakyn product, failure to deliver, delay in

delivery, delivery in nonconforming condition, or

for any breech of contract or duty between

Küryakyn and a customer.

Küryakyn products are often intended for use in

specific applications. Küryakyn makes no

warranty if a Küryakyn product is used in

applications other than intended.

Küryakyn electrical products are warranted for

one (1) year from the date of purchase by the

consumer. L.E.D.’S contained in components of

Küryakyn products will be warranted for defects

in materials and workmanship for 3 years from

the date of purchase where as all other

components shall be warranted for one(1) year.

This includes, but is not limited to; control

modules, wiring, chrome & other components.

Küryakyn makes no warranty of any kind in

regard to other manufacturer¹s products

distributed by Küryakyn. Küryakyn will pass on

all warranties made by the manufacturer and

where possible, will expedite the claim on behalf

of the customer, but ultimately, responsibility for

disposition of the warranty claim lies

with the manufacturer.

ABOUT OUR CATALOG

For purchasing Küryakyn® products, you

can receive a complete catalog free of charge.

Send the Proof-of-Purchase below with

your address to: Küryakyn, P.O. Box 339,

Somerset, WI 54025.

Please indicate either Accessories Catalog for

Harley-Davidson® or GL & Metric Cruisers.

Be sure to ask your local dealer about other

Küryakyn® products, the motorcycle parts and

accessories designed for riders by riders.

©2005 Küryakyn USA® All Rights reserved.

PARTS INCLUDED

1

Hypercharger Including the Following:

2

6-32 x 3/8” Socket Head Cap Screws (in plastic bag in Hyper)

2

#6 Flat Washer (not used) (in plastic bag in Hyper)

3

1⁄4”-20 x 1-5/8” Hex Drive Oval Screw (in plastic bag in Hyper)

1

Dual Velocity Ring (in plastic bag in Hyper) (not used)

1

Round Hyper Filter

1

Yamaha Roadstar Mounting Kit Including the Following:

3

1/4”–20 Nylock Nut

3

1/4”–20 x 5/8” Socket Head Cap Screw — Patched

1

M6

Serrated

Flange

Nut

4

M4–.7mm x 10mm Socket Head Cap Screw

2

M6–1.0mm x 30mm Socket Head Cap Screw

2

M6–1.0mm x 16mm Socket Head Cap Screw

3

M6 Tapered Bolt Caps

1

16” 5/32” Vacuum Line

1

3-Way Barbed “T” Fitting

1

Rubber

Intake

Duct

1

Barbed Connector, 3/8”

1

Main

Support

Bracket

1

“Z”

Bracket

1

“L”

Bracket

1

Lower Mounting Bracket

1

Installation

Instructions

NOTE: NOT ALL OF THE ABOVE PARTS WILL BE USED.


Please read and understand entire instructions before starting installation.


THANK YOU FOR CHOOSING K

ϋ

RYAKYN!

IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY AND/OR

PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION TO ALL
INSTRUCTIONS, WARNINGS, CAUTIONS AND ATTENTION NOTES REGARDING

THE USE AND CARE OF THIS PRODUCT.

WARNING! THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING

THE CONTENTS DESCRIBED HEREIN CAN RESULT IN

POTENTIAL

DEATH

OR

SERIOUS

INJURY.

ATTENTION!

This indication alerts you to the fact that ignoring the contents

described herein may negatively affect product performance and

functionality.

CAUTION!

This indication alerts you to the fact that ignoring the contents

described herein can result in potential injury or material

damage.


TOOLS SUGGESTED

Set of Metric and Standard Hex Wrenches, Set of Metric Combination Wrenches, Phillips
Screwdriver

STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE

PRODUCTPROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.

HYPERCHARGER for YAMAHA

9425

9425-22MC-1011

-cont.-
