Britax Diplomat P321900 - Manual (Page 35)

33
Cover Removal
Remove the infant body pillow. 1
Loosen the harness by lifting the harness adjuster 2
lever while pulling both shoulder straps forward
as far as possible.
Unhook the shoulder straps from the harness 3
yoke on the rear of the child seat (Fig. E).
Pull the upper harness straps through the head 4
restraint and cover to the front of the child seat.
Remove the buckle and belly pad. See page 35. 5
Remove the head restraint portion of the cover. Be careful not to 6
damage the energy-absorbing foam.
Remove the energy-absorbing foam from the head restraint and set 7
aside.
Gently remove the upper portion of the cover by pulling it around the 8
head restraint to the front.
Pull the lower harness straps, buckle tongues, HUGS 9 ™ chest pads, and
chest clip through the lower slots in cover.
Remove the entire cover from the child seat. 10
Care and Maintenance
e
WARNING! Do not take apart the harness. Never remove the
buckle tongues from the harness. They cannot be reattached after
removal. If reassembled incorrectly, the child seat may not perform as
intended.
