Kuryakyn 6350 KINETIC GRIPS - Manual (Page 2)

PAGE
2
STEP 2
Roll or slide the rubber throttle cable adjustment covers to gain access to the adjusters. PIC. 1.
STEP 3
Loosen the jam nuts on the adjusters on both cables; turn the jam nuts and
adjusters until the throttle control is at its loosest point. PIC. 1.
NOTE:
Refer to your service manual for additional information on the
following Steps.
STEP 4
Separate the switch housings by removing the two Torx or Hex screws
(depending on the year of your motorcycle); set them aside, they will be
re-used. You may also have to loosen the screws on the brake clamp to
separate the switch housing halves.
STEP 5 Lift up on the rear cable where it fits into the throttle sleeve; this will provide
enough slack in the cable to remove the cable end and brass ferrule from the
throttle sleeve. PIC 2 Be careful not to lose the brass ferrules; they are
not permanently attached to the cables.
STEP 6 Repeat Step 5 for the other cable.
Ensure that the throttle cables have been properly lubricated
and do not show signs of wear before re-assembly.
STEP 7 Slide the stock grip/throttle sleeve assembly off the handlebar. Set it aside.
STEP 8
Slide the new ISO Grip onto the handlebar. Install the throttle cables in the
reverse order they were removed in Steps 5 and 6.
STEP 9
Re-assemble the switch housing halves and secure them with the screws
removed in Step 4. Ensure that the end of the throttle grip locates in the channel in the switch
housing. Tighten the brake clamp if it was loosened in Step 4.
STEP 10 Adjust the throttle cables and tighten the jam nuts. Ensure proper throttle cable adjustment
and throttle operation before riding the motorcycle. Refer to your model owners’ manual or
service manual for more information.
ROTATE THROTTLE AND CHECK THAT IT MOVES FREELY AND RETURNS
TO CLOSED BEFORE STARTING BIKE. FAILURE TO PROPERLY ADJUST THE
THROTTLE CABLES COULD RESULT IN LOSS OF CONTROL CAUSING
SEVERE INJURY OR DEATH.
It is the installer’s responsibility to ensure that all of the fasteners (including
pre-assembled) are tightened before operation of the motorcycle. Küryakyn will
not provide warranty coverage on products or components lost due to improper
installation or lack of maintenance. Periodic inspection and maintenance are
required on all fasteners.
Clutch Side Procedure
Use extreme care when using the glue included with this kit. Read all
precautions and avoid contact with skin or eyes.
Cover any area of the motorcycle where the glue could possibly drip during
installation.
NOTE: Refer to your service manual for additional information on the following Steps.
STEP 1 Separate the switch housings by removing the two Torx or Hex screws (depending on the year of
your motorcycle); set them aside, they will be re-used. You may also have to loosen the clutch
control clamp to allow the switch halves to separate.
KINETIC GRIPS
INSTALLATION
-cont.-
PIC 1
RUBBER COVERS
JAM NUTS
ADJUSTERS
PIC 2
BRASS FERRULES
