Ride on, Headlight trim ring—black, Installation – Kuryakyn 7276 HEADLIGHT TRIM RING—BLACK User Manual
Page 2
PAGE
2
STEP 5
Install the included pan head
screw through the holes in
the bottom of the trim ring.
PIC 2
STEP 6
Install the custom nut on the
pan head screw. Align the
seam at the bottom, then
tighten the screw. PIC 2
NOTE:
Do not over
tighten the screw.
TIPS FOR PROPER CARE:
Clean often with mild soap and water and a
soft cloth.
Rinse with fresh, clean water then dry with a
soft cloth.
Only use polishes recommended for painted
automotive-type surfaces.
Stay away from abrasive polishes.
Do not over-polish the part.
HEADLIGHT TRIM RING—BLACK
INSTALLATION
Ride On!
PIC 1
HOOK ONE SIDE OF THE
TRIM RING OVER THE OEM
MOUNTING RING. START
AT THE BOTTOM AND
PUSH THE NEW TRIM RING
ON AS YOU GO AROUND
PIC 2
SECURE THE TRIM RING
WITH THE PAN HEAD
SCREW AND CUSTOM NUT.
DO NOT OVER TIGHTEN
THE NUT
ALIGN THE
SEAM
