Series GS-L Glass Tube Flowmeters
KEY INSTRUMENTS • 250 Andrews Road • Trevose, PA 19053 • 800.356.7483 • 215.357.0893 • Fax: 215.357.9239
www.KeyInstruments.com • [email protected]
Rev. Q-113
ORDERING INFORMATION
PREFIX
SCALE LENGTH
RANGE
FITTINGS
VALVE
ELASTOMER
GSL
065 = 65 MM Tube
01-08 Based
S = 316SS
V = Valve
V = Viton
®
150 = 150 MM Tube
On Flow
N = No Valve
Rate Table
I = Inline
FEATURES
• Flow Ranges in both English and SI Units
Air – SCFM and LPM
Water – GPM and LPM
• Glass Tube allows compatibility with most iquids
and gases
• Configuration available:
Inlet Valve, Panel Mount
Outlet Valve, Panel Mount
No Valve, Panel Mount and Inline
• Clear Plastic Shield
• Recessed or Rear Panel Mount
SPECIFICATIONS
Accuracy
± 5% For 65 MM Tube
± 3% For 150 MM Tube
Repeatability
± 1%
Floats
316 Stainless Steel
Black Glass
Housing
Black Anodized Aluminum
Fittings
3/8" FNPT
Wetted Components
316 Stainless Steel with Viton
®
(Buna-N Optional)
Tube
Precision-Formed Borosilicate Glass
Scale Length
65 MM
150 MM
Temperature
Max 250 º F / 121º C
Pressure
Max 250 PSIG / 17 BAR (@100 º F )
SCALE
MOUNTING
A
B
C
D
E
F
G
H
LENGTH
65 MM
Panel
IN.
8-3/8
1-15/16
2-13/16
1-3/16
1-27/ 32
11/16
7
11/ 32
(MM)
(212.7)
(49.2)
(71.4)
(30.2)
(46.8)
(17.5)
(177.8)
(8.7)
150 MM
Panel
IN.
11-15/16
1-15/16
2-13/16
1-3/16
1-27/ 32
11/16
10-9/16
11/ 32
(MM)
(303.2)
(49.2)
(71.4)
(30.2)
(46.8)
(17.5)
(268.3)
(8.7)
65 MM
Inline
IN.
9-3/4
2-1/16
—
—
1-27/ 32
1-3/ 8
7
—
(MM)
(247.7)
(52.4)
(46.8)
(34.9)
(177.8)
150 MM
Inline
IN.
13-5/16
2-1/16
—
—
1-27/ 32
1-3/ 8
10-9/16
—
(MM)
(338.1)
(52.4)
(46.8)
(34.9)
(268.3)
Example: 65 mm tube, 10 scfm range, 316SS fittings, valve, Viton
®
= GSL06502SVV
MAXIMUM FLOWRATE
RANGE
AIR - SCFM
AIR - LPM RANGE
WATER - GPM
WATER - LPM
01
5.0
150
05
1.0
4.0
02
10.0
300
06
2.5
10.0
03
15.0
400
07
4.0
15.0
04
20.0
500
08
5.0
20.0
