DESCRIPTION
Pocket Flowmeters are portable handheld flowmeters designed
to measure flow rates quickly and easliy. Pocket Flowmeters
must be held vertically to ensure accurate readings. Read center
of ball float.
SPECIFICATIONS
Accuracy
±0.2 LPM from 1/8 - 4 LPM
±0.4 LPM from 4 - 8 LPM
±0.6 LPM from 8 - 15 LPM
Float
Stainless Steel
Flow Tube
Polycarbonate
Pressure
100 PSIG Max
Temperature
150°F / 65°C Max
Fittings
Acrylic
Mounting Angle
Vertical
Flow Conditions
Atmosphere
Overall Length
5.32" (135mm)
Diameter
.47" (12mm)
Fitting Size
Fits 3/16" - 7/16"
Inside Diameter Tubing
ORDERING INFORMATION
PART NUMBER
DESCRIPTION
PM2.5OXY
1/8 - 2 1/2 LPM, Oxygen
PM8OXY
1 - 8 LPM, Oxygen
PM15OXY
2 - 15 LPM, Oxygen
PM8AIR
1 - 8 LPM, Air
PM15AIR
2 - 15 LPM, Air
{
