Series FR In-line Flowmeters
Rev. P-025
FR4400, FR4700 & FR4800 DIMENSIONS
Inches / Millimeters
Model
FR4400
FR4700
FR4800
A
5
11
∕
32
135.5
9
1
∕
4
235
11
1
∕
4
286
B
4
102
6
3
∕
4
171.5
8
3
∕
4
222
C
1
3
∕
16
30.2
1
7
∕
8
47.6
1
7
∕
8
47.6
D
1
5
∕
8
41.3
3
76.2
5
127
E
1
25.4
1
1
∕
2
38.1
1
1
∕
2
38.1
F
1
1
∕
8
28.6
1
5
∕
8
41.3
1
5
∕
8
41
G
-
-
1
25.4
1
25.4
H
1/4" MNPT
1/2" FNPT
3/4" FNPT
250 Andrews Road • Trevose, PA 19053 USA • 800.356.7483 • 215.357.0893 • Fax: 215.357.9239
www.KeyInstruments.com • [email protected]
SPECIFICATIONS
Accuracy
Seals
Temperature
Press
Float
Body
Fittings
FR4400 ±5% F.S.
FR4700 & FR4800 ±3% F.S.
Buna-N
150ºF / 65ºC Maximum
100 PSIG / 6.9 Bar Maximum
Aluminum, Stainless Steel
Clear Acrylic
PVC
Dual Scale Air Ranges
SCFM SCFH Model Code
3-12 180-720 FR47A01PI
3-25 180-1500 FR47A03PI
5-50 300-3000 FR47A05PI
LPM LPH Model Code
80-340 4800-20400 FR47A07PI
100-700 6000-42000 FR47A09PI
150-1500 9000-90000 FR47A11PI
Dual Scale Water Ranges
GPM GPH Model Code
0.5-2.5 30-150 FR47L00PI
0.4-5 24-300 FR47L02PI
1-10 60-600 FR47L04PI
LPM LPH Model Code
2-10 120-600 FR47L06PI
2-20 120-1200 FR47L08PI
4-40 240-2400 FR47L10PI
SERIES FR4700 FLOW RATES
Dual Scale Air Ranges
SCFM SCFH Model Code
5-50 300-3000 FR48A01PI
6-70 360-4200 FR48A03PI
10-80 600-4800 FR47A05PI
LPM LPH Model Code
150-1400 9000-84000 FR48A07PI
200-1800 12000-108000 FR48A09PI
200-2200 12000-132000 FR48A11PI
Dual Scale Water Ranges
GPM GPH Model Code
1-12 60-720 FR48L00PI
1.5-15 90-900 FR48L02PI
2-20 120-1200 FR48L04PI
LPM LPH Model Code
5-45 300-2700 FR48L06PI
6-60 360-3600 FR48L08PI
8-70 480-4200 FR48L10PI
SERIES FR4800 FLOW RATES
Air Ranges
SCFH Model Code
6-60 FR44A01PI
15-100 FR44A03PI
25-300 FR44A07PI
LPH Model Code
200-1700 FR44A09PI
500-3000 FR44A11PI
1000-8500 FR44A13PI
Water Ranges
GPH Model Code
1-12 FR44L00PI
4-25 FR44L02PI
6-60 FR44L04PI
LPH Model Code
4-50 FR44L08PI
15-100 FR44L10PI
30-230 FR44L12PI
SERIES FR4400 FLOW RATES
H
External
(2 Places)
10-32
Threaded
Inserts
(2 places)
A
B
F
D
C
E
H Internal
(2 Places)
10-32
Threaded
Inserts
(3 Places)
A
B
D
C
E
F
FR4400
Series
FR4800
Series
G
Center line
of inserts
H Internal
(2 Places)
10-32 UNF
Threaded
Inserts
(3 Places)
A
B
D
C
E
F
FR4700
Series
G.
Center line
of inserts
