The Helman Group 1769 WEIGH SCALE MODULE HM1525 User Manual
Page 17
Chapter
3
Input
(cont.)
Channel 1 Weigh Value (I:e.1)
Weigh value for Channel 1
Channel 2 Weigh Value (I:e.2)
Weigh value for Channel 2.
Channel 1 A/D Trim Value (I:e.3)
Value stored in module for Channel 1. Value should match value on sticker.
Channel 2 A/D Trim Value (I:e.5)
Value stored in module for Channel 2. Value should match value on sticker.
Communication Fault Counter (I:e.6)
Used to troubleshoot noise or ground loops. Associated with module faults to PLC.
Counter value should always be zero.
Page 3-4
